• Water Gas Slip Ring Joint 50RPM Pneumatic Rotary Union
Water Gas Slip Ring Joint 50RPM Pneumatic Rotary Union

Water Gas Slip Ring Joint 50RPM Pneumatic Rotary Union

Product Details:

Place of Origin: Shenzhen , China
Brand Name: JARCH
Certification: CE,FCC,ROHS
Model Number: JSR-JT-MG0118-0308

Payment & Shipping Terms:

Minimum Order Quantity: 1pc
Price: US $ 100 - 300 / Piece
Packaging Details: Gift box or custom packing
Delivery Time: 5-10 days
Payment Terms: Ex-works, L/C,T/T, Western Union, MoneyGram
Supply Ability: 500pcs/week
Get Best Price Contact Now

Detail Information

Material: Stainless Steel Rotor Material: Aluminum
Size: 3/8'' Connection: Flange
Medium: Air Type: Coupling
Max Speed: 50RPM Max Pressure: 1.1Mpa
Max Temperature: 80℃
High Light:

Slip Ring Pneumatic Rotary Union

,

50RPM Pneumatic Slip Ring

Product Description

Water Gas Electricity Slip Ring Rotary Joint Electrical Connector Electrical Rotary Joints Pneumatic Slip Ring





Can work continuously for 365 days
Never leak, current, signal is not interrupted
1/2/4/6/8/10/12/16/24 road gas can be purchased separately or in combination with gas and electricity:
1~120 channels power/signal
Standard interface: G1/8", G1/4", M5 (customizable G3/8", G1/2", etc.)
G1/8" supports 4mm, 6mm, 8mm and other air pipes
G1/4" supports 6mm, 8mm, 10mm and other air pipes
M5 supports 4mm air pipe, can transfer other specifications of air pipe



The electric rotary joint is a precision pneumatic rotary joint that transports a liquid liquid medium from a non-rotatable gas pipe to a dynamic rotary seal, including compressed air, hydrogen, nitrogen, chemical mixed gas, steam, cooling water, hot water, heat. A variety of gas liquids such as oil, petroleum, sulfuric acid, and beverages can be combined to conduct electricity and transmit various control signals. Please contact us for technical consultation, product customization or request for solutions.5mm multiple air pipes;



Water Gas Electricity Slip Ring Rotary Joint Electrical Connector Electrical Rotary Joints Pneumatic Slip Ring



Quick Details:

Material: Stainless Steel Technics:  Type: Coupling
Place of Origin: Shenzhen, China

 Model Number: JSR-JT-MG0118-0308

Brand name: JARCH
Connection: Flange Shape: round Head Code: round
SIZE: 3/8''   Medium: compressed air Rotor material: Aluminum
Max speed: 50RPM Max pressure: 1.1Mpa Max temperature: 80℃





















Packaging & Delivery:

Packaging Details: Standard Export carton Package
Delivery Details:

Delivery time: 15 days after got the payment
Shipping:BY DHL, FedEx, UPS or TNT......



Water Gas Electricity Slip Ring Rotary Joint Electrical Connector Electrical Rotary Joints Pneumatic Slip Ring




Benefits:



1. High-temperature,high-pressure resistant rotating pipe coupling

2. Rugged-construction unions suitable for high pressure, high temperature thermic oil, steam

3The seal is imported from Germany, which guarantee the excellent performance of our rotary union.

4. The design of detachable baseplate structure is convenient for the conversion between single and multi-passsages

5. The use of graphite pallet  balance the compensation of spring, hence it avoids the spring being corroded and prolongs the service life.

6. Ideal for thermal oil and for considerably higher pressures, temperatures

7. Hosing made of ductile cast iron and cover&rotor made of chrome steel

8. Have high temperature resistant spring





Drawing:






Applications:



• Paper Machinery

• steel, corrugating, textiles,

• Dyeing, Rubber, Plastics, Chemical,Machine tool



Installation Instructions:

Your Rotary Systems rotary union is a precision component which, when installed properly, will provide a long, leak free life. Please follow these general guidelines when installing your union:
Connections
Rotary Systems unions should always be installed using flexible connections.  To avoid damage to the bearings, the union needs to find its center during operation.  It is imperative that either the shaft or the housing is not hard-piped.
The housing of the union should be held in a vise and the flexible connection should be installed before installing the union to the machine.
Clean female threads and face of shaft prior to installation. Use Teflon pipe tape or pipe sealant on NPT threads. As a guideline, NPT threads should be hand tight plus 1- 3 turns to seal the threads. When installing parallel threads, appropriate gaskets or o-rings should be used.
There should be a slight, kink-free curve in the hose when installed on the equipment. It is essential the housing or shaft is allowed to float to compensate for any eccentricities and/or misalignment.

Anti-rotation
In many instances, the flexible hose connections are used for anti-rotation. Other applications require an external device for anti-rotation such as a fork around the fittings, pin, yoke or bracket.  Anti-rotation devices need to “float” to prevent damage to the union.
Filtration
To prevent damage to the shaft or the seals, Rotary Systems requires filtration to 10 microns or less.  Failure to do so may invalidate your warranty and cause premature failure.
Lubrication
If your union has grease fittings, lubricate union with no more than two pumps of appropriate grease per fitting.
