Product Details:

Place of Origin: Shenzhen,CN
Brand Name: JARCH
Certification: CE,FCC,ROHS
Model Number: JSR-CRS44

Payment & Shipping Terms:

Minimum Order Quantity: 10 pcs
Price: USD$50-150/PCS
Packaging Details: Standard Export Paper carton or custom packing
Delivery Time: 5-8 WORKING DAYS
Payment Terms: T/T, MoneyGram, Western Union, D/P,PAYPAL
Supply Ability: 10000PCS
Get Best Price Contact Now

Detail Information

USEGE: Industrial Equipment,For Oxygen / Acetylene Only Hose Included: YES
Hose Length: 50ft. Reel Grade: Heavy Duty
Max Pressure: 500 Product Name: Garden Hose Reels Retractable Spring Water Pipe Hose Reel Water Truck Hose Reel
High Light:

Retractable Spring Garden hose reels

,

50ft Hose Garden hose reels

,

stainless steel water truck hose reel

Product Description

JARCH Garden hose reels retractable spring water pipe hose reel water truck hose reel

More details about stainless steel hose reel in PDF click here:stainless steel reel 1-2.pdf



Product Description



JARCH's stainless steel hose reels are ideal for food processing, pre-rinse, wash down, chemical transfer and industrial-solvent handling. Also suitable for coastal, offshore and on-board ship in marine applications where the harsh environment of salt water spray requires the use of stainless hose reels. Swivel include Viton O-rings. Note: Standard latch parts are made from aluminum. Stainless latch parts and fluid path are available as a standard option by placing a -S at the end of the part number.

Garden hose reels retractable spring water pipe hose reel water truck hose reel



Reel Specifications and Dimensions

Weight (lbs) 99
Hose I.D. (in) 3/8"
Hose O.D. (in) .710
Hose Length (ft) 50
Pressure (psi) 2000
Hose End (in) 3/8 NPT(M)
Inlet (in) 3/8 NPT(F)
Reel Outlet (in) 3/8 NPT(F)
Hose Included Yes
Max Temperature (°F) 210
A 25.375"
B 24"
C 8.125"
D 12.875"
E 10"
F 6"

Retractable Spring Garden Hose Reels Water Truck Hose Reel 50ft Hose Included 0

Fluid Path Materials
Seal Type Aflas
Swivel Material Steel
Fluid Path Casting Steel

Retractable Spring Garden Hose Reels Water Truck Hose Reel 50ft Hose Included 1



Benefits



*** Reinforced steel - The stainless steel guide arm and base are stamped with ribs and gussets to insure maximum strength and lightest possible weight;



*** Full flow stress free swivel design - The full flow swivel combines the highest grade seal design and materials with bearing areas to insure maximum service life. The hose is plumbed into the base to eliminate the risk of undue stress on the swivel;



*** Long life drive spring - Declutching arbor virtually eliminates possibility of spring damage due to reverse winding. Only the highest quality spring steel is used and conditioned to insure there are no imperfections offering maximum service life;



*** Quality finish and corrosion resistant - Stainless steel components offer the maximum protection from premature corrosion.



Retractable Spring Garden Hose Reels Water Truck Hose Reel 50ft Hose Included 2



Packaging & Shipping

Packaging Details: Standard Export carton Package
Delivery Details: Delivery time for Sample: 3 days / Delivery time for Order depends on quantity
Shipping:BY DHL, FedEx, UPS or TNT......





MSpring Retractable Gas Welding Hose Reel Included 50 feets Host cable reels

***Can hand crank reels be converted to motor-driven reels?

Yes, JARCH has a number of conversion kits. The reel model and motor type will need to be verified. Listed below are some of the available conversion kits for Series 30000 reels. Contact customer service for more support.

A switch will also be required for all motor driven reels. JARCH has several types of switches and speed controls available. These switches are motor size specific and must be wired properly for the hose reel to function correctly. Have your hose reel model number ready and consult customer service for switch recommendations.





***Can I adjust the guide opening position on an enclosed model hose reel?





  1. Pull hose out of opening and latch into position.
  2. Remove (4) nyloc nuts on the cover.
  3. Pull enclosure off and rotate to desired position.
  4. Replace cover and tighten the (4) nyloc nuts.



  1. Pull hose out of opening and latch into position.
  2. Remove (4) nuts on base.
  3. Pull cover off and remove rubber inserts.
  4. Determine desired guide position and replace rubber inserts in slots not being used.
  5. Place cover on base studs in required position and tighten (4) nuts on base.
