Fiber Optic 12mm 12 Circuits 10A Rotary Joint Slip Rings

Fiber Optic 12mm 12 Circuits 10A Rotary Joint Slip Rings

Product Details:

Place of Origin: Shenzhen , China
Brand Name: JARCH
Certification: CE,FCC,ROHS
Model Number: JSR-TH012-12P10

Payment & Shipping Terms:

Minimum Order Quantity: 5PCS
Price: negotiation
Packaging Details: Gift box or custom packing
Delivery Time: 5-10 days
Payment Terms: Ex works, L/C,T/T, Western Union
Supply Ability: 500pcs/week
Get Best Price Contact Now

Detail Information

Housing Material: Aluminium Alloy Contact Material: Precious Metal:Gold-Gold
Inner Size: 12mm Outer Size: 35mm
Lead Length: 300mm Rings: 2-36
Max Speed: 500RPM (1000~3000RPM Optional) Dielectric Strength: 1000VDC@50Hz
Protection: IP54/IP68
High Light:

12mm Rotary Joint Slip Rings

,

12 Circuits Rotary Joint Slip Rings

Product Description

Product Description

Bore 12mm 12 circuits 10A Through Bore Slip Ring for Bag-forming Packaging Machine fiber optic rotary joint sliprings



JARCH TH Series through bore slip rings are ideally suited for electric slip ring applications where signals and power need to be transferred, and a through hole is required to pass either a shaft or other feed through.

Model Explanation:
12.7mm Through hole Slip Ring , 500RPM 12A slip ring Rotary Connector
The TH012 uses JARCH's fiber brush technology which offers several advantages over conventional slip ring contacts including multiple points of contact per brush bundle, low contact force and low contact wear. It provides an economical, readily available solution when a compact through-bore configuration is required. This unit provides a 6.0mm through-bore for routing hydraulic or pneumatic lines. The 2~5 amps /circuit are available in 1-24 ring.



Suitable for 360 degree continuous rotation of conductive or transmission signals for various devices

Fiber Optic 12mm 12 Circuits 10A Rotary Joint Slip Rings 1





TH12 Series standard percise slip ring,intergrated structure design,with though hole 12.7mm,OD35mm,suitable for rotating application which requires a through hole <=12.7mm( remark:if need a hole <12.7mm,can add a inner bushing)



  • Standard Current is 5A(can be paralleling wires use as 10A)
  • Max rotating speed:250RPM,600RPM,1000RPM (optional);
  • Contact material used precious metal,ensure the stability and working life;
  • More smooth rotation,lower torque and lower dynamic resistance.
  • Voltage: 220V-380V
  • Cable length: 300mm
  • Lead wire: Telfon AWG22


· Unique signal handling performance with minimal electrical circuit noise
· Tight packaging to fit in the most demanding space constraints
· Fully compatible with both analog and TTL control level signals
· Precision ball bearings for long life
· Sealed units available,IP67 optional
· Rugged anodized aluminum construction
· Available with Ethernet
· Rapid delivery



12.7mm Series



12.7mm Through hole Slip Ring , 500RPM 12A slip ring Rotary Connector

Fiber Optic 12mm 12 Circuits 10A Rotary Joint Slip Rings 3

Fiber Optic 12mm 12 Circuits 10A Rotary Joint Slip Rings 4

Fiber Optic 12mm 12 Circuits 10A Rotary Joint Slip Rings 5



Applications of JARCH 12.7mm Stable Performance Through Bore Slip Ring , 500RPM 12A Rotary Connector:


• Exhibit/display equipment

• Packaging / wrapping machinery

• Semiconductor handling systems

• Industrial machinery

• rotary index tables

• Process control equipment

• Heavy equipment turrets or cable reels

• Emergency lighting, robotics Palletizing machines, Option

• Medical equipment | rotary sensors, emergency lighting, robotics

• Miniature cable reels


Installation Instructions:

Shaft Mounted



1.Mounting the slip ring to the shaft;
2.Fix rotor to the rotating Axis with 4pcs screw;
3.Fix the anti-rotation tab with screw,make sure the slip ring smooth rotatingly.

12.7mm Through hole Slip Ring , 500RPM 12A slip ring Rotary Connector

Flange mounted:

12.7mm Through hole Slip Ring , 500RPM 12A slip ring Rotary Connector
